Product Details:
Place of Origin: China
Brand Name: MOUETTE
Certification: ISO/TS 16949:2009, ISO 9001:2008
Model Number: 4.5mm, 5mm, 8mm, 17mm, 1/2 inch, 1 inch, 2 inch, 3 inch, 4 inch Steel Balls
Payment & Shipping Terms:
Minimum Order Quantity: 10000
Price: USD0.001 per Piece
Packaging Details: Plastic bags, Cartons and European Standard Plywood Case.
Delivery Time: 3-45 working days.(Huge Quantity Stocks Available))
Payment Terms: L/C, T/T, D/A, Western Union, Paypal
Supply Ability: 1,000,000 Pieces per Month.

4.5mm 5mm Precision Steel Balls 8mm 17mm 1 Inch AISI 304 Stainless Steel Bearings G10 G25 G100

Description
Name: AISI 304 Stainless Steel Balls Metal Ball Steel Sphere Type Ranges: Stainless Steel Balls
Material: Stainless Steel AISI304 Size Ranges: 1mm To 150mm (1/32″ To 5.3/4″)
Grade Range: ISO 3290 G 10-G500 Typical Hardness: Annealed – Rockwell B 75-95. Not Annealed – Rockwell C 25-39.
Corrosion Resistance: Resist Attack By Oxidizing Solutions, Foodstuffs, Sterilizing Solution And Most Organic Chemicals. Applications: Couplings, Valves And Pumps.
High Light:

4.5mm Precision Steel Balls

,

5mm Precision Steel Balls

,

304 stainless steel ball bearings

4.5mm 5mm 8mm 17mm 1 inch AISI 304 Stainless Steel Balls G10 G25 G100



Stainless Steel Balls

Mouette supply high-quality stainless steel balls for specific applications.

We mainly make:

  • Stainless steel balls: AISI304
  • Stainless steel balls: AISI316
  • Stainless steel balls: AISI420
  • Stainless steel balls: AISI440C





AISI304 Stainless Steel Balls

Profile
Precision AISI 304 stainless steel balls are used when conditions require corrosion performance and toughness not available in hardenable stainless steels. Principal applications are in couplings, valves and pumps.

Specifications

Carbon Nickel Chromium Manganese Silicon Phosphorus Sulfur
0.08% max. 8% – 10.5% 18% – 20% 2.00% 1.00% 0.00% 0.30% max



Characteristics
Low magnetic permeability: annealed, 1.003; cold worked, 1.10; severely cold worked, 10.0. High tensile strength at elevated temperatures. AISI 304 stainless steel work-hardens rapidly.
AISI 304 stainless steel balls of this material are passivated.

Corrosion Resistance
AISI 304 stainless steel balls resist attack by oxidizing solutions, foodstuffs, sterilizing solution and most organic chemicals. They are susceptible to attack by halogen acids and moderately resistant to the sulphur acids.

Typical Hardness
Annealed – Rockwell B 75-95. Not annealed – Rockwell C 25-39.

Ball Sizes
Available in sizes from 1mm to 150mm in grades 50 through 1000.
