Product Details:
|
| Name: | Thermoplastic Bearing Units | Housing: | Thermoplastic Housing(PBT), White, Green Or Black Color |
|---|---|---|---|
| Insert Bearings' Material: | Stainless Steel 440C, Stainless Steel 420 | Lubricant: | Industrial Grease Or Food Grade Grease |
| Mounting Method:: | Set Screw Locking | Compliance With Standard: | ISO, JIS, North American Standard |
| Applications: | Food And Beverage Processing And Packaging, Conveyor Systems, Elevator Systems, Agricultural Machinery | Other Features: | Outer Ring With Grease Groove And Holes,at Same Side Of Setscrew |
| High Light: | tapped Thermoplastic Bearing Units,440c stainless steel pillow block bearing,420 stainless steel pillow block bearing |
||
Thermoplastic Bearing Units Tapped base Stainless Steel Insert Bearing SUCTB205
SUCTB2 series short leg thermoplastic tapped base pillow block unit, Stainless steel insert bearings,with food grade grease and silicon rubber seal, setscrew locking. Thermoplastic Housings are made in a High-grade glass-filled thermoplastic polyester, which has a high tensile strenth and can operate in temperatures to 102°C.
Housing: Thermoplastic housing(PBT),white, green or black color
Zerk fittings: Stainless steel 304
Insert bearing: Stainless steel 440
Steel ball:Stainless steel 440
Retainer: Stainless steel 201
Seal: Silicon rubber seal
Lubricant: Industrial grease, or Food grade grease
Outer ring with grease groove and holes,at same side of setscrew
With anti-rotation pin at opposite side of setscrew
Mainly Applications:
Thermoplastic Bearing Units Tapped base Stainless Steel Insert Bearing SUCTB2 Specifications:
|
Bearing Unit Part No. |
Bore Dia | Dimension(mm) |
Bearing Part No. |
Housing Part No. |
NW (kg) |
||||||||||
| d | h | a | e | b | g | W | F | t | S | B | |||||
| in | mm | ||||||||||||||
| SUCTB201 SUCTB201-8 SUCTB202 SUCTB202-10 SUCTB203 SUCTB203-11 |
1/2
5/8
11/16 |
12
15
17 |
33.3 |
73 |
50.8 |
38 |
11 |
65 |
12.7 |
3/8-16 |
12.7 |
31 |
SUC201 SUC201-8 SUC202 SUC202-10 SUC203 SUC203-11 |
STB203 |
0.70 |
| SUCTB204 SUCTB204-12 |
3/4 |
20 |
33.3 |
73 |
50.8 |
38 |
11 |
65 |
12.7 |
3/8-16 |
12.7 |
31 |
SUC204 SUC204-12 |
STB204 |
0.72 |
| SUCTB205 SUCTB205-14 SUCTB205-15 SUCTB205-16 |
7/8 15/16 1 |
25 |
36.5 |
76 |
50.8 |
38 |
12 |
71 |
12.7 |
3/8-16 |
14.3 |
34.1 |
SUC205 SUC205-14 SUC205-15 SUC205-16 |
STB205 |
0.93 |
| SUCTB206 SUCTB206-17 SUCTB206-18 SUCTB206-19 SUCTB206-20 |
1-1/16 1-1/8 1-3/16 1-1/4 |
30 |
42.9 |
102 |
76.2 |
38 |
12 |
87 |
16 |
7/16-14 |
15.9 |
38.1 |
SUC206 SUC206-17 SUC206-18 SUC206-19 SUC206-20 |
STB206 |
1.41 |
|
SUCTB207 SUCTB207-20 SUCTB207-21 SUCTB207-22 SUCTB207-23 |
1-1/4 1-5/16 1-3/8 1-7/16 |
35 |
47.6 |
108 |
82.6 |
48 |
12 |
95 |
19 |
1/2-13 |
17.5 |
42.9 |
SUC207 SUC207-20 SUC207-21 SUC207-22 SUC207-23 |
STB207 |
1.86 |
| SUCTB208 SUCTB208-24 SUCTB208-25 |
1-1/2 1-9/16 |
40 |
49.2 |
117 |
88.9 |
48 |
12 |
100 |
19 |
1/2-13 |
19.0 |
49.2 |
SUC208 SUC208-24 SUC208-25 |
STB208 |
2.33 |
|
SUCTB209 SUCTB209-26 SUCTB209-27 SUCTB209-28 |
1-5/8 1-11/16 1-3/4 |
45 |
54.0 |
127 |
95.3 |
51 |
12 |
108 |
19 |
1/2-13 |
19.0 |
49.2 |
SUC209 SUC209-26 SUC209-27 SUC209-28 |
STB209 |
2.79 |
| SUCTB210 SUCTB210-29 SUCTB210-30 SUCTB210-31 SUCTB210-32 |
1-13/16 1-7/8 1-15/16 2 |
50 |
57.2 |
140 |
101.6 |
51 |
14 |
117.5 |
22 |
5/8-11 |
19.0 |
51.6 |
SUC210 SUC210-29 SUC210-30 SUC210-31 SUC210-32 |
STB210 |
3.18 |
