SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing

SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing
SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing

Large Image :  SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing

Product Details:
Place of Origin: China
Brand Name: MOUETTE
Certification: ISO/TS 16949:2009, ISO 9001:2008
Model Number: SL045016-D-PP-2NR - Cylindrical Roller Bearing
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: USD15 per Piece
Packaging Details: Plastic bags, Single box, then Cartons and European Standard Plywood Case.
Delivery Time: 5-45 working days.(Huge Quantity Stocks Available))
Payment Terms: L/C, T/T, D/A, Western Union, Paypal
Supply Ability: 500,000 Pieces per Month.
Contact Now

SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing

Description
Name: Cylindrical Roller Bearings Full Complement Locating Bearing Also Known As: NNF5004ADA-2LSV
Category: Cylindrical Roller Bearing Material: 100Cr6, GCr15, AISI 52100
Design: New Outer Contour Sealing: PP Material, Contact Seal On Both Sides
Holding Rings: 2NR (two Retaining Rings Included) Radial Internal Clearance: Group N (CN)
Tolerance Class: Normal Standard Precision Number Of Rolling Element Rows: Double-row
High Light:

SL045016 full complement roller bearings

,

full complement roller bearings gcr15

,

Cylindrical Roller Locating Bearing

SL045016-D-PP-2NR Cylindrical Roller Bearings Full Complement Locating Bearing



Cylindrical roller bearing SL04..-D-PP-2NR, full complement roller set, two-row, locating bearing, central rib on outer ring, 3 ribs on inner ring, type SL04 Series.



FEATURES:

  • Double row sheave bearings
  • Single and double sealed versions are available with suffix P or PP
  • Locating bearing
  • External snap ring grooves
  • Inner ring and outer ring oil holes



Cylindrical Roller Bearings Full Complement Locating Bearing SL04..-D-PP-2NR Series Details:

Bearing Code Dimensions Loading Rating Limiting speed Mass
d D B d1 D1 C r Dyn. Stat. Fatigue limit load nG
Cr Cor Cur
mm KN rpm kg
SL04 5004PP 20 42 30 31 40.2 29 0.3 40.5 49 7.2 4000 0.2
SL04 5005PP 25 47 30 35.5 45.2 29 0.3 44.5 58 7.9 3600 0.24
SL04 5006PP 30 55 34 41 53 33 0.3 50 67 9.2 3000 0.37
SL04 5007PP 35 62 36 46.5 60 35 0.3 63 88 11.8 2600 0.48
SL04 5008PP 40 68 38 51.5 65.8 37 0.3 76 103 14.7 2400 0.56
SL04 5009PP 45 75 40 57.5 72.8 39 0.3 92 130 18.1 2200 0.7
SL04 5010PP 50 80 40 62 77.8 39 0.3 97 142 19.8 2000 0.76
SL04 5011PP 55 90 46 69 87.4 45 0.3 115 175 24 1800 1.18
SL04 5012PP 60 95 46 74 92.4 45 0.6 120 189 26 1700 1.26
SL04 5013PP 65 100 46 79 97.4 45 0.6 125 203 28 1600 1.33
SL04 5014PP 70 110 54 85 107.1 53 0.6 168 265 35 1400 1.87
SL04 5015PP 75 115 54 90 112.1 53 0.6 194 300 39.5 1400 1.96
SL04 5016PP 80 125 60 97.5 122.1 59 0.6 203 325 42.5 1300 2.71
SL04 5017PP 85 130 60 104.5 127.1 59 0.6 211 350 45 1200 2.83
SL04 5018PP 90 140 67 109.5 137 66 0.6 305 510 62 1100 3.71
SL04 5019PP 95 145 67 114 142 66 0.6 315 530 64 1100 3.88
SL04 5020PP 100 150 67 118 147 66 0.6 330 550 66 1000 3.95
SL04 5022PP 110 170 80 132 167 79 0.6 395 680 78 900 6.57
SL04 5024PP 120 180 80 141.5 176 79 0.6 410 740 83 900 7.04
SL04 5026PP 130 200 95 157 196 94 0.6 540 960 105 800 10.5
SL04 5028PP 140 210 95 166 206 94 0.6 610 1100 118 750 11.1
SL04 5030PP 150 225 100 176 221 99 0.6 710 1260 131 700 13.3
SL04 5032PP 160 240 109 189.5 236 108 0.6 740 1360 140 650 16.6
SL04 5034PP 170 260 122 201 254 121 0.6 960 1750 174 600 22.6
SL04 5036PP 180 280 136 218.5 274 135 0.6 1140 2130 205 550 30.1
SL04 5038PP 190 290 136 226 284 135 0.6 1160 2210 211 550 31.5
SL04 5040PP 200 310 150 243.5 304 149 0.6 1350 2600 245 500 40.8
SL04 5044PP 220 340 160 260.5 334 159 1 1570 3050 280 480 52.5
SL04 5048PP 240 360 160 279.5 354 159 1 1630 3300 295 440 56
SL04 5052PP 260 400 190 305.5 394 189 1.1 2380 4700 405 400 84.5
SL04 5056PP 280 420 190 321.5 354 189 1.1 2600 5200 440 380 90
SL04 5060PP 300 460 218 347.5 453 216 1.1 3000 5800 480 340 126

SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 0

SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 1



SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 2



SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 3



SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 4



SL045016 Full Complement Roller Bearings Gcr15 Cylindrical Roller Locating Bearing 5
