Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring
Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

Large Image :  Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

Product Details:
Place of Origin: China
Brand Name: MOUETTE
Certification: ISO/TS 16949:2009, ISO 9001:2008
Model Number: NK06/10TN, NK08/12, NK10/10, NK15/12, NK16/20, NK18/20, NK20/16, NK25/16, RNA4901, RNA4903, RNA4904, RNA6901, RNA6903, RNA6904, RNA5903, NKS25, NKS30, NKS32
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: USD1 per Piece (Inquired for details)
Packaging Details: Plastic bags, Cartons and European Standard Plywood Case.
Delivery Time: 3-45 working days.(Huge Quantity Stocks Available))
Payment Terms: L/C, T/T, D/A, Western Union, Paypal
Supply Ability: 500,000 Pieces per Month.
Contact Now

Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring

Description
Name: Solid Collar Needle Roller Bearings Needle Bearing Type: Machined Needle Roller Bearing Without Inner Ring
Bearing Material: Chrome Steel 100Cr6, GCr15, AISI 52100 Closure Type: Open
Flanges: With Flanges Inch - Metric: Inch
Separable: No Number Of Rows Of Rollers: Single Row
Lubrication Hole Type: Lubrication Groove & Hole Operating Temperature Range: -20 To +120 °C
Customized: Standard Or Customized Are Available Other Features: 2 Rib Outer Ring | Oil Hole And Lube Groove
High Light:

nk15 solid needle roller bearings

,

nk12 solid needle roller bearings

,

single row rna 4906 bearing

Solid Collar Needle Roller Bearings Without Inner Ring NK15/12 RNA4906



Single row needle roller bearing with machined rings, with flanges, without inner ring

Single row needle roller bearings without an inner ring consist of an outer ring with a needle roller and cage assembly. They are an excellent choice for compact bearing arrangements in applications where hardened and ground raceways can be provided on the shaft. The outer ring includes two integral flanges to guide the bearing axially and an annular groove with one or more lubrication holes to facilitate relubrication.

  • High radial load carrying capacity
  • High stiffness
  • Low cross-sectional height
  • Accommodate axial displacement in both directions



Solid Collar Needle Roller Bearings Without Inner Ring Specifications:

Shaft

Dia-meter

 Bearing Designation

Mass

Approx

 Boundary Dimensions Basic Load Rating Limiting Speed
Current Code Original Code Fw D C Dynamic Static Oil
mm g mm N rpm
5 NK5/10TN   2.9 5 10 10 2100 1400 36780
NK05/08     5 10 8
NK05/10TN-OH     5 10 12 2350 1920 39000
NK05/12TN   3.7 5 10 12 3000 2650 39000
6 NK06/10     6 12 10 2600 2200 37000
NK06/10TN     6 12 10 2600 2200 37000
NK06/12TN   5.7 6 12 12 3350 3150 37000
RNA6X13X8TN     6 13 8
7 NK07/10   6.9 7 14 10 2850 2650 34000
NK07/12   8.2 7 14 12 3650 3600 34000
7.8 RNA7.8169     7.8 16 9
8 NK08/12TN   8.3 8 15 12 3950 4100 32000
NK08/12   8.7 8 15 12 3950 4100 32000
NK08/16   12 8 15 16 5100 5800 32000
NK08/16TN     8 15 16 5100 5800 32000
RNA8X19X9     8 19 9
RN8X14X8     8 14 8
RNA496     8 15 10
RNA8X15X10TN     8 15 10
9 NK09/12   10.3 9 16 12
10 NK10/12TN 462409K 10 10 17 12 4750 5300 29000
  5624097 16.6 10 17 15 4860 7100 29000
NK10/10     10 17 10
NK10/12     10 17 12
NK10/16     10 17 16 6200 7800 29000
NK10/16TN     10 17 16 6200 7800 29000
NKS10     10 19 13 5800 6000 29000
12 NK12/12TN 644097 11.8 12 19 12 6000 6400 27000
  5624098 15.4 12 19 15 6400 7100 27000
NK12/16   16.8 12 19 16 8200 9800 27000
14 NK14/16 4624900K 20.8 14 22 16 10100 11500 25000
NKS14   27 14 25 16 1400 13800 24000
RNA4900 4624900 24.4 14 22 13 8500 9000 25000
RNA6900 6634900 29.1 14 22 22 12800 15600 25000
NK14/12     14 22 12
NK14/20     14 22 20 12800 15600 25000
15 NK15/12 644800K 18.5 15 23 12 8600 11000 21000
RNA152815   31.7 15 28 15 13600 17200 24000
  7948/15 16.1 15 22 12 8200 9800 8500
15   644302 18.2 15 25 12 10600 13500 17000
NK15/16   21.8 15 23 16 10700 12700 24000
NK15/20   26.7 15 23 20 13600 17200 24000
NK152312     15 23 12
NK152512     15 25 12
16 NK16/16   20.8 16 24 16 11300 13900 23000
NK16/20 624701 23.9 16 24 20 10400 16800 23000
RNA4901 4624901 16.6 16 24 13 6400 8900 15500
RNA6901 6634901 28.7 16 24 22 14000 18600 15500
NKS16   30 16 28 16 14900 15000 20000
NK162516     16 25 16
NK162616     16 26 16
17 NK17/16 644903K 21.5 17 25 16 9000 13500 14000
NK17/20 RNA172520 30 17 25 20 15000 20000 23000
18 NK18/20   30.5 18 26 20 15500 19800 22000
NK18/16     18 26 16 12500 16200 22000
19 NK19/16     19 27 16 13000 17000 22000
20 NK20/16 644802 25.7 20 28 16 10500 13800 21000
NK20/20 624802 29.3 20 28 20 11500 21800 21000
NK202616   20.8 20 26 16 9600 10800 21000
NK202620     20 26 20 9600 10800 21000
NKS20   46.8 20 32 20 20000 23000 20000
NK203312SX   29.1 20 33 12 13000 18000 11000
  6624101 24.3 20 28 25 13000 17500 11000
RNA4902 4624902 20.5 20 28 13 11000 12900 12000
RNA6902 6634902 35.4 20 28 23 10800 12800 12000
NK20/16     20 32 16 13000 25000 12000
RNA5902     20 28 18
21 NK21/12     21 29 12
NK21/16     21 29 16 13500 18700 21000
NK21/20     21 29 20
22 NK22/16 NK223016 29.2 22 30 16 13500 18000 11500
  NK223516 34.6 22 35 16 18600 20800 11500
NKS22   60.2 22 35 20 21500 25000 17000
RNA4903 4644903 20.7 22 30 13 12000 16800 16300
RNA5903     22 30 18
RNA6903 6634903 39.8 22 30 23 14000 19900 16300
  624703 53 22 35 25 24500 28000 14100
  634704L 42.5 22 30 30 17700 27000

16500

22

   644704 27.4 22 28 16 10500 15000 16500
  NK223516 49.4 22 35 16 18600 20800 16500
NK22/20     22 30 20
23   634704KA 37.5 23 30 30 18600 29000 15000
24 NK24/16     24 32 16
NK24 X 33.5 X 7.5     24 33.5 7.5
25 NK25/16 624904 30 25 33 16 12900 20400 15000
NK25/20 644804 38.4 25 33 20 16800 28500 15000
RNA4904 4644904 50.8 25 37 17 11900 16500 15000
RNA6904 6634904 97.7 25 37 30 26000 43000 15000
NKS25   65 25 38 20 25800 31000 16300
  624704 100.1 25 35 25 14900 22400 16500
NK25/30 644804K 63 25 33 30 18800 30500 165000
NK253326     25 33 26
NK253422     25 34 22
NK253425     25 34 25
NK253820     25 38 20
NK253825     25 38 25
NK254517.5     25 45 17.5
26 NK26/16   30 26 34 16 15000 23000 16300
NK26/20   40 26 34 20 17000 30000 16300
27 NK27 X 40 X 25     27 40 25
28 RNA283833   99.8 28 38 33 33000 57000 12000
  F3833 99.8 28 38 33 33000 57000 12000
NKS28   80 28 42 20 25900 33500 15000
NK28/20   53 28 37 20 22000 34000 16500
NK28/30     28 37 30 33000 57000 12000
RNA69/22 63549/22   28 39 30
29 NK29/20     29 38 20 21900 34000 15000
NK29/30     29 38 30 32500 57000 15000
30 NK30/20 644805 57.9 30 40 20 20600 32000 15000
NK30/30   95 30 40 30 31500 50000 15000
RNA4905 4624905 57 30 42 17 23600 31500 14000
RNA6905 6634905 106.5 30 42 30 39000 59000 14000
  624905 68 30 42 20 20000 32000 15000
NK304013     30 40 13
NK304430     30 44 30
NK304630     30 46 30
NK305017     30 50 17
30 NKS30     30 45 17 32000 40000 14000
RNA305225     30 52 25
30.5 NK30.5 X 50 X 16     30.5 50 16
NK30.5 X 50 X 17     30.5 50 17
31 NK31.75 X 44.45 X 31.75     31.75 44.45 22
32 NK32/20 624705 75.4 32 42 20 22600 33500 15000
RNA49/28 46449/28K 80 32 45 17 17400 30000 13000
NAS32   100 32 47 22 31000 40000 13000
RNA69/28   125 32 45 30 39500 61300 13000
  644906 42 32 38 11 10750 30500 12000
  644706 193 32 50 35 40500 63000 12000
NKS32   100 32 47 22 31000 40000 12000
NK32/30     32 42 30 33500 60000 12000
RNA324527     32 45 27
34 NK345034     34 50 34
NK345035     34 50 35
35 NK35/20 644806 70 35 45 20 13800 26900 12000
RNA4906 4624906 62.8 35 47 17 17000 30500 12000
RNA6906 6634906 116 35 47 30 35000 67000 12000
  644907 161 35 51   43500 71000 12000
NK354512     35 45 12
NK354830     35 48 30
NK355034     35 50 34
NK355236     35 52 36
RNA354527     35 45 27
RNA5906   108 35 47 23
RNA355730     35 57 30
RNA355734     35 57 34



Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring 0

Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring 1



Nk15 Nk12 Solid Needle Roller Bearingss Single Row RNA 4906 Without Inner Ring 2
