Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33

Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33
Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33

Large Image :  Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33

Product Details:
Place of Origin: China
Brand Name: MOUETTE
Certification: ISO/TS 16949:2009, ISO 9001:2008
Model Number: NNU4960 K/W33, NNU4964 K/W33, NNU4968 K/W33, NNU4972 K/W33, NNU4976 K/W33, NNU4980 K/W33, NNU4984 K/W33, NNU4088 K/W33, NNU4092 K/W33, NNU4096 K/W33
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: USD20 per Piece (Inquired for details)
Packaging Details: Plastic bags, Cartons and European Standard Plywood Case.
Delivery Time: 3-45 working days.(Huge Quantity Stocks Available))
Payment Terms: L/C, T/T, D/A, Western Union, Paypal
Supply Ability: 100,000 Pieces per Month.
Contact Now

Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33

Description
Name: Super Precision Double Row Cylindrical Roller Bearing Bore Type: Tapered, Taper 1:12
Cage Material: Machined Brass Cage Bearing Material: Bearing Quality Steel
Locating Feature , Bearing Outer Ring: Lubrication Holes And Lubrication Groove In Outer Ring Number Of Rolling Element Rows: Double-row Design
Radial Internal Clearance: Group 1 (C1) Operating Temperature: -20 °C ~ 120 °C
High Light:

double row cylindrical roller bearing super precision

,

double row cylindrical roller bearing NNU4960

,

high speed cylindrical roller bearings NNU4992

Super Precision Double Row Cylindrical Roller Bearing NNU4960 NNU4992 K/W33



Super precision cylindrical roller bearings NNU49, non-locating bearing, double row, with tapered bore, taper 1:12, separable, with cage





Features

The super precision cylindrical roller bearings comprise solid outer rings, solid inner rings with a tapered bore (taper 1:12) and cylindrical roller and cage assemblies with cages made from polyamide, brass or PEEK (polyetheretherketone). The outer ring is removable and can thus be mounted separately from the rest of the bearing package. The inner ring is only removable in the case of series NNU49.





Super-precision double row cylindrical roller bearing with tapered bore and lubrication feature NNU design specifications:

Part Number Dimension Basic Load Rating (KN) Limiting Speed Mass
(mm) (rpm) (kg)
d D B rsmin Fw Ew Cr Cor Grease Oil 　
NNU4860 300 380 80 2.1 324 - 690 1760 1300 1600 21.7
NNU4960 300 420 118 3 336 - 1230 2870 1200 1500 51.9
NNU4960/W33 300 420 118 3 336 - 1230 2870 1200 1500 51.9
NNU4960 K 300 420 118 3 336 - 1230 2870 1200 1500 51.9
NNU4960 K/W33 300 420 118 3 336 - 1230 2870 1200 1500 51.9
NNU3160 300 500 160 5 358 - 1760 3150 900 1200 126
　 　 　 　 　 　 　 　 　 　 　 　
NNU4864 320 400 80 2.1 346 - 700 1840 1200 1500 22.8
NNU4964 320 440 118 3 359 - 1260 3050 1100 1400 54.9
NNU4964/W33 320 440 118 3 359 - 1260 3050 1100 1400 54.9
NNU4964 K 320 440 118 3 359 - 1260 3050 1100 1400 53.4
NNU4964 K/W33 320 440 118 3 359 - 1260 3050 1100 1400 53.4
NNU3064 320 480 121 4 366 - 1350 2670 1100 1400 76.9
NNU4064 320 480 160 4 366 - 1960 4300 1100 1400 103
NNU3164 320 540 176 5 383 - 2090 3750 800 1100 154
　 　 　 　 　 　 　 　 　 　 　 　
NNU4968 340 460 118 3 739 - 1350 3400 1100 1400 57.8
NNU4968/W33 340 460 118 3 739 - 1350 3400 1100 1400 57.4
NNU4968 K 340 460 118 3 739 - 1350 3400 1100 1400 55.2
NNU4968 K/W33 340 460 118 3 739 - 1350 3400 1100 1400 55
NNU4068 340 520 180 5 393 - 2420 5350 860 1000 141
NNU4068/W33X 340 520 180 5 393 - 2420 5350 860 1000 136
NNU4168 340 580 243 5 402 - 4000 7550 780 940 267
　 　 　 　 　 　 　 　 　 　 　 　
NNU4972 360 480 118 3 399 - 1390 3550 1000 1300 60.6
NNU4972/W33 360 480 118 3 399 - 1390 3550 1000 1300 60.1
NNU4972 K 360 480 118 3 399 - 1390 3550 1000 1300 58.8
NNU4972 K/W33 360 480 118 3 399 - 1390 3550 1000 1300 58.4
NNU3072 360 540 134 5 413 - 1630 3240 900 1100 108
　 　 　 　 　 　 　 　 　 　 　 　
NNU4976 380 520 140 4 426 - 1880 4600 900 1200 88.8
NNU4976/W33 380 520 140 4 426 - 1880 4600 900 1200 88.2
NNU4976 K 380 520 140 4 426 - 1880 4600 900 1200 86.2
NNU4976 K/W33 380 520 140 4 426 - 1880 4600 900 1200 85.8
NNU3176 380 620 194 5 449 - 2620 4950 750 900 228
NNU4176 380 620 243 5 449 - 4130 8350 700 850 288
　 　 　 　 　 　 　 　 　 　 　 　
NNU4880 400 500 100 2.1 430 - 905 2540 900 1200 45.7
NNU4980 400 540 140 4 446 - 1700 4500 850 1100 95
NNU4980/W33 400 540 140 4 446 - 1700 4500 850 1100 94
NNU4980 K 400 540 140 4 446 - 1700 4500 850 1100 91
NNU4980 K/W33 400 540 140 4 446 - 1700 4500 850 1100 90.6
NNU3180 400 650 200 6 463 - 2770 5400 780 950 262
NNU4180 400 650 250 6 463 - 4700 9550 750 900 328
　 　 　 　 　 　 　 　 　 　 　 　
NNU4984 420 560 140 4 466 - 2000 5015 800 1000 92
NNU4984/W33 420 560 140 4 466 - 2000 5015 800 1000 91.3
NNU4984 K 420 560 140 4 466 - 2000 5015 800 1000 90
NNU4984 K/W33 420 560 140 4 466 - 2000 5015 800 1000 89.3
NNU3084 420 620 150 5 469 - 2130 4450 750 900 155
NNU4084 420 620 200 5 469 - 3400 7850 720 850 209
NNU4084/W33 420 620 200 5 469 - 3450 7500 720 850 204
NNU3184 420 700 224 6 500 - 3550 6800 700 830 347
　 　 　 　 　 　 　 　 　 　 　 　
NNU4888 440 540 100 2.1 470 - 950 2790 840 950 49.5
NNU4888/W33 440 540 100 2.1 470 - 950 2790 840 950 49
NNU4888 K/W33 440 540 100 2.1 470 - 950 2790 840 950 49
NNU4988 440 600 160 4 490 - 　 　 750 900 135
NNU4988/W33 440 600 160 4 490 - 　 　 750 900 134.2
NNU4988 K 440 600 160 4 490 - 　 　 750 900 132
NNU4988 K/W33 440 600 160 4 490 - 　 　 750 900 131.3
NNU3088/W33 440 650 157 6 487 - 2360 4900 700 850 178
NNU4088/W33 440 650 212 6 487 - 3850 8250 650 800 214
NNU4088 K/W33 440 650 212 6 487 - 3850 8250 650 800 214
NNU4188/W33 440 720 280 6 511 - 5650 111500 600 700 452
　 　 　 　 　 　 　 　 　 　 　 　
NNU4892 K/W33 460 580 118 3 497 - 1150 3250 750 900 73
NNU4892/W33 460 580 118 3 497 - 1150 3250 750 900 75
NNU4992 460 620 160 4 510 - 2000 5400 700 850 133
NNU4992/W33 460 620 160 4 510 - 2000 5400 700 850 132
NNU4992 K 460 620 160 4 510 - 2000 5400 700 850 129
NNU4992 K/W33 460 620 160 4 510 - 2000 5400 700 850 128
NNU4092/W33 460 680 218 6 524 - 4250 9300 600 700 238
NNU4092 K/W33 460 680 218 6 524 - 4250 9300 600 700 235
NNU4192 K 460 760 300 7.5 537 - 6350 13000 550 650 533
NNU4192 460 760 300 7.5 537 - 6350 13000 550 650 535
　 　 　 　 　 　 　 　 　 　 　 　
NNU4996 480 650 170 5 534 - 2300 6150 650 750 156
NNU4996/W33 480 650 170 5 534 - 2300 6150 650 750 155.2
NNU4996 K 480 650 170 5 534 - 2300 6150 650 750 154
NNU4996 K/W33 480 650 170 5 534 - 2300 6150 650 750 153.2
NNU4096/W33 480 700 218 6 544 - 4200 9600 550 650 272
NNU4096 K/W33 480 700 218 6 544 - 4200 9600 550 650 265
NNU4196/W33 480 790 308 7.5 558 - 7000 14400 500 600 591
NNU4196 K/W33 480 790 308 7.5 558 - 7000 14400 500 600 585



Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 0

Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 1



Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 2



Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 3



Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 4



Double Row Cylindrical Roller Bearing Super Precision High Speed NNU4960 NNU4992 K/W33 5
