Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row

Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row
Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row

Large Image :  Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row

Product Details:
Place of Origin: China
Brand Name: MOUETTE
Certification: ISO/TS 16949:2009, ISO 9001:2008
Model Number: NJ2304E, NJ2305E, NJ2306E, NJ2307E, NJ2308E, NJ2309E, NJ2310E, NJ2311E, NJ2312E, NJ2313E, NJ2314E, NJ2315E, NJ2316E, NJ2317E, NJ2318E, NJ2319E, NJ2320E, NJ2322E, NJ2324E, NJ2326E, NJ2328E, NJ2330E, NJ2332E, NJ2334E, NJ2340E
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: USD2 per Piece (Inquired for details)
Packaging Details: Plastic bags, Cartons and European Standard Plywood Case.
Delivery Time: 3-45 working days.(Huge Quantity Stocks Available))
Payment Terms: L/C, T/T, D/A, Western Union, Paypal
Supply Ability: 500,000 Pieces per Month.
Contact Now

Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row

Description
Name: Cylindrical Roller Bearings Bearing Type: NJ Design
Material: 52100 Chrome Bearing Steel, Or Equivalent Bore Type: Straight Bore
Ring Separation: Separable Outer Ring Flanges: 2 On Outer Ring, 1 On Inner Ring
Internal Clearance: C0 Closure Type: Open
Number Of Rolling Element Rows: Single-row Design Tolerance Class: Normal / Customized
High Light:

semi locating straight bore bearing

,

straight bore bearing NJ2310E

,

metric roller bearing single row

Cylindrical Roller Bearing Straight Bore Single Row Semi Locating Bearing NJ2310E



Cylindrical roller bearing with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ



Main Features:

  • Cylindrical roller bearing with a removable inner ring suitable for high radial loads
  • CN (normal) radial clearance for applications where thermal expansion is not a factor
  • Single row roller bearing for high radial loads with low friction
  • Removable inner ring in open bearing allows for lubrication in place
  • Semi-locating bearing (two ribs on the outer ring, one rib on the inner ring) for supporting axial forces in one direction
  • Polyamide cage is lightweight and produces less noise and vibrations than brass cages
  • Metric unit measurements for industry consistency



Single Row Cylindrical Roller Bearing Straight Bore and Semi Locating Bearing NJ Series Specifications:

Bearing Code Dimensions Mass Basic Load Ratings Limiting Speed
d D B rsmin d1 D1 Fw, Ew dynamic static
Cr Cor
mm kg KN 　 rpm
NJ2304E 20 52 21 1.1 — 42.4 27.5 0.219 41.5 39 14000
NJ2305E 25 62 24 1.1 — 50.7 34 0.356 57 56 12000
NJ2306E 30 72 27 1.1 — 58.9 40.5 0.54 73.5 75 10000
NJ2307E 35 80 31 1.5 — 66.3 46.2 0.736 91.5 98 9000
NJ2308E 40 90 33 1.5 — 75.6 52 0.978 112 120 7500
NJ2309E 45 100 36 1.5 — 83.5 58.5 1.33 137 153 6700
NJ2310E 50 110 40 2 — 91.2 65 1.77 163 186 6300
NJ2311E 55 120 43 2 — 101 70.5 2.27 200 228 5600
NJ2312E 60 130 46 2.1 — 110 77 2.83 224 260 5000
NJ2313E 65 140 48 2.1 — 119 82.5 3.38 245 285 4800
NJ2314E 70 150 51 2.1 — 127 89 4.09 275 325 4500
NJ2315E 75 160 55 2.1 — 136 95 5.04 325 390 4000
NJ2316E 80 170 58 2.1 — 144 101 6 355 425 3800
NJ2317E 85 180 60 3 — 153 108 6.84 365 450 3600
NJ2318E 90 190 64 3 — 162 113.5 8.19 430 530 3400
NJ2319E 95 200 67 3 — 170 121.5 9.58 455 585 3400
NJ2320E 100 215 73 3 — 182 127.5 12.3 570 72 3200
NJ2322E 110 240 80 3 — 201 143 16.9 630 800 2800
NJ2324E 120 260 86 3 — 219 154 23.5 780 1020 4300
NJ2326E 130 280 93 4 — 236 167 29.2 915 1220 3800
NJ2328E 140 300 102 4 — 252 180 36.6 1020 1400 3600
NJ2330E 150 320 108 4 — 270 193 43.8 1160 1600 3200
NJ2332E 160 340 114 4 — 286 204 52.3 1320 1830 3000
NJ2334E 170 360 120 4 — 299 216 62.3 1500 2080 2800
NJ2340EX 200 420 138 5 — 350 247 97.2 2040 2900 2400

Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row 0

Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row 1



Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row 2



Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row 3



Semi Locating Straight Bore Bearing NJ2310E Metric Roller Bearing Single Row 4
