Chrome Steel Miniature Needle Roller Bearings Single Row Full Complement RNAV4005

Full Complement Needle Roller Bearings Single Row Without Inner Ring RNAV4005

As for the full complement needle roller bearing with inner ring, the outer ring has the oil hole. The lubricating oil can be fed in from the oil hole. The outer ring has the double shoulders. As for the full complement needle roller bearing without inner ring, since the inner ring has no shoulder and cage, the inner ring, outer ring, complete set of needles can be mounted respectively. It is a suitable for parts of which the radial size is limited. The surface of shaft journal fitted with it is acted directly as rolling surface. It is requested that the surface hardness be no less than HRC60, surface roughness, no more than 0.63μm. This kind of full complement bearing, with inner ring or without inner ring, does not limit the axial shift of shaft and housing.

Since this kind of bearing has no cage, the needles rotate without correct guiding, they rub heavily against each other and the bearing has the low limiting rotational speed.

Features:

• Bearing steel long life bearing, smooth, low noise.
• Fully loaded needle roller bearings, open, no cage, Without the inner ring, please add lubricating oil or oil before use
• Straight bore for fitting on a conventional cylindrical shaft

Full Complement Needle Roller Bearings Single Row Without Inner Ring Specifications:
